IDB2 HAD
(Integrated Dynamic Brake for Highly Autonomous Driving)

IDB2 HAD is an expansion of Mando’s IDB2 product line, with specific design features added to ensure that typical single point failures are avoided. Features such as: two separate power/communication connectors, double wound motor, fully separated and sealed ECUs, etc, ensure continued and safe operation.

IDB2 HAD also offers full brake by wire technology by having the option for a separated e-pedal.

Product

Value Proposition

  • The extension system for autonomous driving (Full Redundant Brake System)

    Applied the Dual ECU, Double winding motor, 2-Chamber pump, and Dual sensor.
    Thanks to redundant design, It controls braking even in single fail situation.

    Features such as: two separate power/communication connectors, double wound motor, fully separated and sealed ECUs, etc, ensure continued and safe operation.

  • Convenient packing for OEM vehicles

    Equipped in vehicle as 2-Box System, Modular HAD and M-Pedal.
    It improves packaging scope

  • Improve NVH Performance

    Apply the Dry M-pedal specialized to the pedal feeling and minimize the operating noise of electrical brake flowing into the vehicle compartment through the dash panel.
